Flanges

Flanges are used to connect valves, pipes, pumps and other equipment to make a pipework system. Typically flanges are welded or threaded, and two flanges are connected together by bolting them with gaskets to provide a seal that provides easy access to the piping system. These Flanges are available in various types such as slip on flanges, weld neck flanges, blind flanges, and socket weld flanges, etc. Below we have explained the various types of flanges used in the piping systems depends on their sizes other factors.

Standards	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc
Dimensions	ASME B16.5 ASME B16.47 ASME B16.48 ASME B16.36 EN 1092-1 DIN BS JIS
Sizes	1/2″ (15 NB) to 48″ (1200NB)
Class/Pressure	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc
Flange Face Type	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Forms	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges

Stainless & Duplex Steel:

Range	15 NB UP TO 600 NB IN 150 LBS , 300 LBS, 400 LBS , 600 LBS , 900 LBS , 1500 LBS , 2500 LBS / TABLE 2.5 , TABLE 6 , TABLE 10, TABLE 16,TABLE 25 , TABLE 40, TABLE 64, TABLE 160, TABLE 320, TABLE 400
Form	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Stainless Stell	ASTM A182 F304/F304L F316/F316L F321 F347 F904L
Duplex Steel	F51 F53 F55 F60 F61

Carbon & Alloy Steel

Range	15 NB UP TO 600 NB IN 150 LBS , 300 LBS, 400 LBS , 600 LBS , 900 LBS , 1500 LBS , 2500 LBS / TABLE 2.5 , TABLE 6 , TABLE 10, TABLE 16,TABLE 25 , TABLE 40, TABLE 64, TABLE 160, TABLE 320, TABLE 400
Form	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Carbon Steel	ASTM / ASME A 105 , ASTM / ASME A 350 LF 2 .
Alloy Steel	ASTM / ASME A 182 GR F 5, F 9 , F 11 , F 12 , F 22 , F 91

Nickel & Copper Alloy:

Range	15 NB UP TO 600 NB IN 150 LBS , 300 LBS, 400 LBS , 600 LBS , 900 LBS , 1500 LBS , 2500 LBS / TABLE 2.5 , TABLE 6 , TABLE 10, TABLE 16,TABLE 25 , TABLE 40, TABLE 64, TABLE 160, TABLE 320, TABLE 400
Form	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Nickel Alloy	Monel Inconel Hastelloy Alloy 20 Nickel Alloys
Copper Alloy	ASTM / ASME SB 61 UNS NO. C 92200 & ASTM / ASME SB 62 UNS NO. C 83600. ASTM / ASME SB 151 UNS NO. 70600 , 71500 , C 70600 ( CU -NI- 90/10) , C 71500 ( CU -NI- 70/30) ASTM / ASME SB 152 UNS NO C 10100 , C 10200 , C 10300 , C 10800 , C 12000, C 12200

Hastelloy

Grades	Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000
Size	1/2″NB to 12″NB
Standard	ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE
Types	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Features	Durability Corrosion resistance Dimensional accuracy High strength Excellent finish

Inconel:

Grades	Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750
Size	1/2 inch – 48 inch (15mm – 1200mm)
Standard	ANSI/ASME B16.5, ANSI B16.47 API, DIN, JIS, BS
Types	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Features	Durability Corrosion resistance Dimensional accuracy High strength Excellent finish

Incoloy:

Grades	ncoloy 800, incoloy 825, Incoloy 925, Incoloy a-286, Incoloy DS
Flanges Grade	ASTM A 182 F 304/L; 316/L; 317/L; 309; 310; 321; 347; 904L.
Type	SORF, BLRF, WNRF, SOLJ
Class	50 To 3000
Flanges range	DN15 Upto DN1800 IN 150 LBS, 300 LBS, 400 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS / TABLE 2.5, TABLE 6, TABLE 10, TABLE 16, TABLE 25, TABLE 40, TABLE 64, TABLE 160, TABLE 320, TABLE 400
Types	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Features	Durability Corrosion resistance Dimensional accuracy High strength Excellent finish

Monel:

Grades	Monel 400, Monel k500.
Range	1/2″ NB to 60″ NB
Types	Slip-On Flanges Weld Neck Flanges Blind Flanges Socket Weld Flanges Threaded Flanges Lap Joint Flanges Spectacle Blind Flanges Orifice Flanges Reducing Flanges Long Weld Neck Flanges
Features	Durability Corrosion resistance Dimensional accuracy High strength Chemical resistance Excellent finish

Titanium:

Material	Titanium.
Grade	Gr2, Gr5, Gr7, Gr9.
Standards	DIN,ASTM,BS.
Application	Bicycles,Motors,Chemicals.
Standards	DIN,ASTM,BS.
Strengths	Superior Quality, Fast delivery, Competitive price as well as humanized after-sales service.
Features	Low density, rustless, good antiwear property, high strength.
Size	Set the size according to the customers’ requirements.

Technical Disclaimer:

Product grades, dimensions, standards, finishes and availability are subject to material grade, manufacturing route, applicable specification, quantity and customer requirements. Materials can be supplied with Mill Test Certificates (MTC) and inspection documentation wherever specified. Custom sizes and specifications are available subject to feasibility and supplier/mill availability.
